MEA® ACO Hygienic Box Channel

ACO hygienic box channel offers a sanitary drainage solution crafted for precision, durability, and long-term performance. Manufactured using stainless steel 304 or 316L, it features a V-shaped bottom that promotes faster water discharge and improves cleaning efficiency. With smooth surfaces and large internal radii—≥3mm inside corners and ≥10mm at the bottom—it reduces contamination risks and simplifies disinfection. The slip-resistant gratings enhance workplace safety, while edge in-fill ensures structural stability during installation and operation. Designed for sensitive environments, this box channel supports various outlet configurations with optional filters and water traps. Custom sizing enables seamless integration into complex layouts without compromising hygiene.

Features

• Stainless steel 304 or 316L offers high corrosion resistance

• V-shaped bottom enhances self-cleaning flow and hygiene

• Slip-resistant gratings improve safety under wet conditions

• Internal corner radius ≥3mm; bottom radius ≥10mm for easy disinfection

• Smooth surface design reduces bacterial accumulation

• Edge in-fill stabilizes system within floor structures

• Custom sizes and multiple outlet options available

Applications and Benefits

• Ideal for food production, commercial kitchens, cleanrooms, and pharmaceutical zones

• Ensures easy cleaning and compliance with hygiene regulations

• Prevents fluid stagnation and cross-contamination

• Modular construction speeds up installation and layout adaptation

• Supports integration with filtration and odor trap units

Installation and Layout Flexibility

The ACO hygienic box channel integrates into various flooring systems with flexible outlet placements. Its smooth interior and rounded corners allow uninterrupted cleaning cycles, while the edge in-fill strengthens floor stability and finish. Installers can select from an array of outlet units—including vertical or horizontal discharge, removable filters, and water traps—to match system requirements. Custom fabrication ensures compatibility with floor slope and load demands.

FAQs

Q1: What makes the ACO hygienic box channel suitable for sterile environments?

A: It uses hygienic stainless steel, rounded corners, and a smooth, easy-to-clean surface.

Q2: Can it be used with odor traps and filters?

A: Yes, multiple outlet units are available, including those with filters and water traps.

Q3: Does the V-bottom affect cleaning?

A: It improves water flow and assists in flushing out contaminants naturally.

Q4: Are custom dimensions supported?

A: Absolutely. We offer full customization to meet site-specific layout needs.

Q5: How does edge in-fill help during installation?

A: It secures the unit within the floor and provides added durability under load.

Why Choose ACO Hygienic Box Channel

Choosing the ACO hygienic box channel ensures a clean, safe, and efficient drainage system built for high-demand environments. The combination of stainless materials, thoughtful geometry, and modular outlet flexibility provides superior hygiene control and reliable performance. Whether you're outfitting a food processing area or a sterile lab, this solution delivers long-term cleanliness, durability, and adaptability.
