MEADRAIN® EN Drain Channels

MEA drain channels deliver exceptional performance in demanding drainage applications. The MEADRAIN® Supreme series combines lightweight polymer concrete with high structural strength, reinforced by ductile iron gratings and cast iron edge rails. These channels support the passage of aircraft, trucks, and containers, offering long-term reliability under F900 loading. Smooth internal surfaces accelerate runoff, while chemical resistance and watertight construction help protect surrounding groundwater. With PROFIX® or bolted grating fixings, MEA drain channels stay secure even under dynamic traffic loads.

Features

• Lightweight polymer concrete channel body for easy handling and strength

• Integrated cast iron edge rails increase structural load resistance

• Smooth internal walls enhance drainage velocity and reduce sediment buildup

• Ductile iron gratings support high wheel load and resist deformation

• Sealed body structure protects surrounding soil and groundwater

• PROFIX® or bolt-down grating systems provide vibration-proof security

• Certified to EN 1433, Class F900, Type M

Applications and Benefits

• Suitable for airport aprons, seaports, heavy transport zones, and loading docks

• Handles extreme point loads like aircraft wheels and container haulers

• Prevents leakage or groundwater contamination in hazardous environments

• Maintains long-term flow performance with low-maintenance surfaces

• Reduces installation time due to lightweight, modular 1-meter sections

Installation and Layout Flexibility

Each drain channel is 1000 mm in length and ranges from 67.6 to 115.2 kg per meter, depending on the model configuration. The opening width is 300 mm, with a total width of 354 mm and height of 490 mm. These standardized dimensions support fast integration into both new and retrofit projects. The channels can be combined with a range of ductile iron gratings and secured using MEA's proprietary PROFIX® or bolted systems to ensure long-term structural safety and reliability.

FAQs

Q1: What is the load class of MEA drain channels?

A: They meet EN 1433 F900 standards, supporting extreme loads such as airport and container traffic.

Q2: Are these channels resistant to chemicals?

A: Yes, the polymer concrete body offers excellent chemical and corrosion resistance.

Q3: How do the grating fixings work?

A: Gratings can be secured with PROFIX® quick-lock or traditional bolted mechanisms.

Q4: Can they be used in high-speed vehicle zones?

A: Absolutely. The robust cast iron edges and locked gratings prevent loosening under dynamic loads.

Q5: What prevents sediment accumulation inside the channel?

A: Smooth inner walls enhance water velocity and reduce the chance of debris buildup.

Why Choose Drain Channels

MEA drain channels offer a high-performance drainage solution tailored for infrastructure where strength, reliability, and safety cannot be compromised. From aircraft taxiways to logistics hubs, these channels withstand punishing loads while ensuring clean, fast, and secure water removal. Their sealed bodies protect groundwater, and their smooth interior supports ongoing performance with minimal maintenance. With certified load ratings and modular design, MEA drain channels represent an advanced choice for professionals who demand both engineering precision and installation efficiency.
