Slot End Outlet Channel with Outlet Box

MEA slot end outlet channel delivers efficient, discreet surface drainage with a narrow slot opening and direct end discharge. Designed for applications requiring both performance and aesthetic subtlety, it features a V-shaped bottom that accelerates flow and enhances self-cleaning. The modular stainless steel structure offers weld-free joints that eliminate contamination risks, while the hidden slot profile integrates seamlessly with surrounding flooring. Adjustable installation options and corrosion-resistant materials make it a preferred solution for areas requiring hygienic, fast-flowing water management.

Features

• Narrow slot design enables discreet and continuous drainage

• V-shaped bottom improves hydraulic performance and reduces debris accumulation

• End outlet ensures direct discharge into downstream pipe systems

• Weld-free joints enhance hygiene and simplify maintenance

• Modular form allows flexible layout and expansion

• Made of stainless steel for durability and corrosion resistance

Applications and Benefits

• Ideal for commercial kitchens, cleanrooms, retail spaces, and minimalist architectural zones

• Combines aesthetics with performance in water removal

• Eliminates stagnant water zones and promotes cleanliness

• Easily connects to existing piping at the end of the run

• Reduces labor and downtime during installation and cleaning

Installation and Layout Flexibility

With a modular design, the slot end outlet channel integrates smoothly into linear drainage systems. The end outlet connects directly to building drainage, while the narrow opening stays flush with the floor surface. Weld-free connections reduce on-site labor, and adjustable legs (if included) enable fine-tuned slope control. It fits in narrow corridors or along architectural transitions without disrupting design integrity or drainage efficiency.

FAQs

Q1: What distinguishes the slot end outlet channel from standard trench drains?

A: It combines hidden drainage with efficient end-outlet discharge, offering both function and aesthetic integration.

Q2: Can it be used in hygienic environments?

A: Yes, the stainless steel body and weld-free design make it compliant with strict sanitary requirements.

Q3: Is the outlet position fixed?

A: The outlet is at the end by default, but it can be customized to meet project-specific plumbing needs.

Q4: How does the V-bottom design help?

A: It speeds up water flow and supports self-cleaning by reducing residue accumulation.

Q5: Does it support long drainage runs?

A: Absolutely. Modular connections allow you to extend the system to suit layout length and design.

Why Choose Slot End Outlet Channel

The MEA slot end outlet channel is the solution for projects demanding both clean visual lines and high-performance drainage. Its modular form supports fast installation and flexible layout, while the narrow slot maintains surface aesthetics. Designed with sanitation and structural durability in mind, this product addresses the challenges of subtle drainage while ensuring long-term reliability, hygiene, and easy maintenance.
